ACE25 series - 25W AC to DC converter

ACE25系列 - 25W 交流对直流转换器

ACE25系列 - 25W 交流对直流转换器(图1)

＊2"X1"尺寸
＊可提供50W峰值负载能力
＊弹性保持时间(易于延长)
＊低空载功率损耗< 0.3W
＊低电流100uA
＊±10%输出可调功能
＊OCP / OVP / OTP




  • 90~264VAC 输入范围
  • 小巧尺寸
  • 效率高达 88%
  • < 0.3W 的无负载消耗
  • 低洩漏电流 100uA
  • 增强绝缘 4kVac
  • Class II 设计
  • 封装电源模块
  • 过压和短路保护
  • 设计符合标准 EN55032 & CIRSS/FCC class B
  • 设计符合标准 UL62368-1 EN62386-1 IEC62368-1
  • 设计符合标准 UL60601-1 EN60601-1 IEC60601-1
  • 设计符合标准 UL60335-1 EN60335-1 IEC60335-1



选型表

型号输入输出效率
电压电流电压电流功率
范围标称满载VAWTyp. %
ACE25-050S-2590-2642300.13552584
ACE25-120S-2590-2642300.13122.125.285
ACE25-150S-2590-2642300.13151.6725.185
ACE25-240S-2590-2642300.13241.0525.286
ACE25-360S-2590-2642300.13360.725.287
ACE25-480S-2590-2642300.13480.5325.487



详细规格需求请联系我司销售人员。
